SPECIFICATION
Circuitry: 1C-2P
Contact Rating: 0.3A 4VDC
Contact Resistance: 70 milliohms max. @ 1A/5VDC
Insulation Resistance: 100 mega-ohms min. @ 500VDC for 1 minute
Dielectric Strength: 500VAC for 1 minute
Life: 10,000
Operating Force: 150+/-100gf
Travel: 1.5mm
Soldering: Auto (260+/5C for 3s), Manual (350+/10C for 3s)
RoHS Compliant: yes
Packaging: bulk or 3000 switches per reel
