SPECIFICATION
Circuitry: 2C-2P
Timing: non-shorting
Contact Rating: 6VDC 0.3A
Contact Resistance: 70 milli-ohms max. @ 1A/5VDC
Insulation Resistance: 100 mega-ohms min. @ 500VDC for 1 minute
Dielectric Strength: 500VAC for 1 minute
Life: 10,000
Operating Force: 200+/-100gf
Travel: 2mm
Soldering: Auto (260+/5C for 3s), Manual (350+/10C for 3s)
RoHS Compliant: yes
Packaging: bulk or 800 switches per reel
